osgeo::proj::cs::SphericalCS Class Referencefinal

A three-dimensional coordinate system in Euclidean space with one distance measured from the origin and two angular coordinates. More...

#include <coordinatesystem.hpp>

Inheritance diagram for osgeo::proj::cs::SphericalCS:
Inheritance graph
[legend]
Collaboration diagram for osgeo::proj::cs::SphericalCS:
Collaboration graph
[legend]

Static Public Member Functions

static SphericalCSNNPtr create (const util::PropertyMap &properties, const CoordinateSystemAxisNNPtr &axis1, const CoordinateSystemAxisNNPtr &axis2, const CoordinateSystemAxisNNPtr &axis3)
 Instanciate a SphericalCS. More...

- Static Public Member Functions inherited from osgeo::proj::common::IdentifiedObject
static IdentifiedObjectNNPtr create (const util::PropertyMap &properties)
 Instanciate a new IdentifiedObject. More...


Additional Inherited Members

- Public Types inherited from osgeo::proj::util::IComparable
enum  Criterion { Criterion::STRICT, Criterion::EQUIVALENT }
 Comparison criterion. More...

- Public Member Functions inherited from osgeo::proj::cs::CoordinateSystem
const std::vector< CoordinateSystemAxisNNPtr > & axisList () PROJ_CONST_DECL
 Return the list of axes of this coordinate system. More...

bool isEquivalentTo (const util::IComparable *other, util::IComparable::Criterion criterion=util::IComparable::Criterion::STRICT) const override
 Returns whether an object is equivalent to another one. More...

- Public Member Functions inherited from osgeo::proj::common::IdentifiedObject
const metadata::IdentifierNNPtrname () PROJ_CONST_DECL
 Return the name of the object. More...

const std::string & nameStr () PROJ_CONST_DECL
 Return the name of the object. More...

const std::vector< metadata::IdentifierNNPtr > & identifiers () PROJ_CONST_DECL
 Return the identifier(s) of the object. More...

const std::vector< util::GenericNameNNPtr > & aliases () PROJ_CONST_DECL
 Return the alias(es) of the object.

const std::string & remarks () PROJ_CONST_DECL
 Return the remarks.

bool isDeprecated () PROJ_CONST_DECL
 Return whether the object is deprecated. More...

std::string alias () PROJ_CONST_DECL
 Return the (first) alias of the object as a string. More...

int getEPSGCode () PROJ_CONST_DECL
 Return the EPSG code. More...

bool isEPSG (int code) PROJ_CONST_DECL
 Return whether the object has a identifiers() in the EPSG code space.

- Public Member Functions inherited from osgeo::proj::io::IWKTExportable
std::string exportToWKT (WKTFormatter *formatter) const

- Static Public Attributes inherited from osgeo::proj::common::IdentifiedObject
static const std::string NAME_KEY
 Key to set the name of a common::IdentifiedObject. More...

static const std::string IDENTIFIERS_KEY
 Key to set the identifier(s) of a common::IdentifiedObject. More...

static const std::string ALIAS_KEY
 Key to set the alias(es) of a common::IdentifiedObject. More...

static const std::string REMARKS_KEY
 Key to set the remarks of a common::IdentifiedObject. More...

static const std::string DEPRECATED_KEY
 Key to set the deprecation flag of a common::IdentifiedObject. More...


Detailed Description

A three-dimensional coordinate system in Euclidean space with one distance measured from the origin and two angular coordinates.

Not to be confused with an ellipsoidal coordinate system based on an ellipsoid "degenerated" into a sphere. A SphericalCS shall have three axis associations.

Remarks
Implements SphericalCS from ISO 19111:2018

Member Function Documentation

SphericalCSNNPtr osgeo::proj::cs::SphericalCS::create ( const util::PropertyMap properties,
const CoordinateSystemAxisNNPtr axis1,
const CoordinateSystemAxisNNPtr axis2,
const CoordinateSystemAxisNNPtr axis3
)
static

Instanciate a SphericalCS.

Parameters
propertiesSee General properties.
axis1The first axis.
axis2The second axis.
axis3The third axis.
Returns
a new SphericalCS.

The documentation for this class was generated from the following files:
